Class: Qgs25DRendererWidget

class qgis.gui.Qgs25DRendererWidget(layer: QgsVectorLayer | None, style: QgsStyle | None, renderer: QgsFeatureRenderer | None)

Bases: QgsRendererWidget

Constructor

Parameters:
actionEvent(self, a0: QActionEvent | None)
apply()
changeEvent(self, a0: QEvent | None)
changeSymbolAngle(self)

Change marker angles of selected symbols

changeSymbolColor(self)

Change color of selected symbols

changeSymbolOpacity(self)

Change opacity of selected symbols

changeSymbolSize(self)

Change marker sizes of selected symbols

changeSymbolUnit(self)

Change units mm/map units of selected symbols

changeSymbolWidth(self)

Change line widths of selected symbols

childEvent(self, a0: QChildEvent | None)
closeEvent(self, a0: QCloseEvent | None)
connectNotify(self, signal: QMetaMethod)
contextMenuEvent(self, a0: QContextMenuEvent | None)
contextMenuViewCategories(self, p: QPoint)
copy(self)
create(layer: QgsVectorLayer | None, style: QgsStyle | None, renderer: QgsFeatureRenderer | None) QgsRendererWidget | None

Static creation method

Parameters:
Return type:

Optional[QgsRendererWidget]

createDataDefinedSizeLegendWidget(self, symbol: QgsMarkerSymbol | None, ddsLegend: QgsDataDefinedSizeLegend | None) QgsDataDefinedSizeLegendWidget | None

Creates widget to setup data-defined size legend. Returns newly created panel - may be None if it could not be opened. Ownership is transferred to the caller.

customEvent(self, a0: QEvent | None)
destroy(self, destroyWindow: bool = True, destroySubWindows: bool = True)
disconnectNotify(self, signal: QMetaMethod)
dragEnterEvent(self, a0: QDragEnterEvent | None)
dragLeaveEvent(self, a0: QDragLeaveEvent | None)
dragMoveEvent(self, a0: QDragMoveEvent | None)
dropEvent(self, a0: QDropEvent | None)
enterEvent(self, a0: QEvent | None)
event(self, a0: QEvent | None) bool
focusInEvent(self, a0: QFocusEvent | None)
focusNextChild(self) bool
focusNextPrevChild(self, next: bool) bool
focusOutEvent(self, a0: QFocusEvent | None)
focusPreviousChild(self) bool
hideEvent(self, a0: QHideEvent | None)
initPainter(self, painter: QPainter | None)
inputMethodEvent(self, a0: QInputMethodEvent | None)
isSignalConnected(self, signal: QMetaMethod) bool
keyPressEvent(self, event: QKeyEvent | None)

Overridden key press event to handle the esc event on the widget.

Parameters:

event – The key event

keyReleaseEvent(self, a0: QKeyEvent | None)
leaveEvent(self, a0: QEvent | None)
metric(self, a0: QPaintDevice.PaintDeviceMetric) int
mouseDoubleClickEvent(self, a0: QMouseEvent | None)
mouseMoveEvent(self, a0: QMouseEvent | None)
mousePressEvent(self, a0: QMouseEvent | None)
mouseReleaseEvent(self, a0: QMouseEvent | None)
moveEvent(self, a0: QMoveEvent | None)
nativeEvent(self, eventType: QByteArray | bytes | bytearray, message: PyQt5.sip.voidptr | None)
paintEvent(self, a0: QPaintEvent | None)
paste(self)
pasteSymbolToSelection(self)

Pastes the clipboard symbol over selected items.

Added in version 3.10.

receivers(self, signal: PYQT_SIGNAL) int
refreshSymbolView(self)
renderer(self) QgsFeatureRenderer | None
Return type:

Optional[QgsFeatureRenderer]

resizeEvent(self, a0: QResizeEvent | None)
selectedSymbols(self) List[QgsSymbol]

Subclasses may provide the capability of changing multiple symbols at once by implementing the following two methods and by connecting the slot contextMenuViewCategories(const QPoint&).

sender(self) QObject | None
senderSignalIndex(self) int
setSymbolLevels(self, levels: Iterable[QgsLegendSymbolItem], enabled: bool)

Sets the symbol levels for the renderer defined in the widget.

The levels argument defines the updated list of symbols with rendering passes set.

The enabled arguments specifies if symbol levels should be enabled for the renderer.

Added in version 3.20.

sharedPainter(self) QPainter | None
showEvent(self, a0: QShowEvent | None)
tabletEvent(self, a0: QTabletEvent | None)
timerEvent(self, a0: QTimerEvent | None)
updateMicroFocus(self)
wheelEvent(self, a0: QWheelEvent | None)
