Class: QgsDataDefinedSizeLegendWidget

Widget for configuration of appearance of legend for marker symbols with data-defined size.

QgsDataDefinedSizeLegendWidget allowing customization of data-defined size legends

QgsDataDefinedSizeLegendWidget allowing customization of data-defined size legends

Class Hierarchy

Inheritance diagram of qgis.gui.QgsDataDefinedSizeLegendWidget

Base classes

QgsPanelWidget

Base class for any widget that can be shown as a inline panel

QWidget

QObject

QPaintDevice

Methods

dataDefinedSizeLegend

Returns configuration as set up in the dialog (may be None).

class qgis.gui.QgsDataDefinedSizeLegendWidget[source]

Bases: QgsPanelWidget

__init__(ddsLegend: QgsDataDefinedSizeLegend | None, ddSize: QgsProperty, overrideSymbol: QgsMarkerSymbol | None, canvas: QgsMapCanvas | None = None, parent: QWidget | None = None)

Creates the dialog and initializes the content to what is passed in the legend configuration (may be None). The ddSize argument determines scaling of the marker symbol - it should have a size scale transformer assigned to know the range of sizes. The overrideSymbol argument may override the source symbol: this is useful in case when the symbol is given from outside rather than being set inside QgsDataDefinedSizeLegend.

Parameters:
dataDefinedSizeLegend(self) QgsDataDefinedSizeLegend | None[source]

Returns configuration as set up in the dialog (may be None). Ownership is passed to the caller.

Return type:

Optional[QgsDataDefinedSizeLegend]
