Class: QgsAdvancedDigitizingFloater¶

The QgsAdvancedDigitizingFloater class is widget that floats next to the mouse pointer, and allow interaction with the AdvancedDigitizing feature. It proxies display and actions to QgsMapToolAdvancedDigitizingDockWidget.

Note

This class is a technology preview and unstable API.

Added in version 3.8.

Class Hierarchy¶

Base classes¶

QWidget
QObject
QPaintDevice

Enums

FloaterItem

Available floater items

Methods

`active`	Whether the floater is active or not.
`itemVisibility`	Returns `True` if the floater item visibility setting is enabled.
`setActive`	Set whether the floater should be active or not.
`setItemVisibility`	Set whether the floater item should be visible or not.

class qgis.gui.QgsAdvancedDigitizingFloater[source]¶

Bases: QWidget

__init__(canvas: QgsMapCanvas | None, cadDockWidget: QgsAdvancedDigitizingDockWidget | None)

Create an advanced digitizing floater widget

Parameters:

canvas (Optional[QgsMapCanvas]) – The map canvas on which the widget operates
cadDockWidget (Optional[QgsAdvancedDigitizingDockWidget]) – The cadDockWidget to which the floater belongs

Added in version 3.8.

class FloaterItem(*values)¶

Bases: IntEnum

Available floater items

XCoordinate:
YCoordinate:
MCoordinate:
ZCoordinate:
Angle:
CommonAngleSnapping:
Distance:
Bearing:

Angle = 32¶

Bearing = 256¶

CommonAngleSnapping = 64¶

Distance = 128¶

MCoordinate = 8¶

XCoordinate = 2¶

YCoordinate = 4¶

ZCoordinate = 16¶

class FloaterItems¶
class FloaterItems(f: QgsAdvancedDigitizingFloater.FloaterItems | QgsAdvancedDigitizingFloater.FloaterItem)
class FloaterItems(a0: QgsAdvancedDigitizingFloater.FloaterItems): Bases: object

active(self) → bool[source]¶

Whether the floater is active or not. Note that the floater may be active but not visible (e.g. if the mouse is not over the canvas).

Added in version 3.8.

Return type:: bool

itemVisibility(self, item: QgsAdvancedDigitizingFloater.FloaterItem) → bool[source]¶

Returns True if the floater item visibility setting is enabled.

Parameters:: item (QgsAdvancedDigitizingFloater.FloaterItem) – floater item

Added in version 3.32.

Return type:: bool

setActive(self, active: bool)[source]¶

Set whether the floater should be active or not. Note that the floater may be active but not visible (e.g. if the mouse is not over the canvas).

Parameters:: active (bool)

Added in version 3.8.

setItemVisibility(self, item: QgsAdvancedDigitizingFloater.FloaterItem, visible: bool)[source]¶

Set whether the floater item should be visible or not.

Parameters:

item (QgsAdvancedDigitizingFloater.FloaterItem) – floater item
visible (bool)

Added in version 3.32.
